[My Journey to CCIE Automation #10] From Docker Compose to Kubernetes

My journey continues

👋 Hi, I’m Bjørnar Lintvedt

I’m a Senior Network Consultant at Bluetree, working at the intersection of networking and software development.

As mentioned in my first blog post, I’m preparing for the CCIE Automation lab exam — Cisco’s most advanced certification for network automation and programmability. I’m documenting the journey here with weekly, hands-on blog posts tied to the blueprint.

During my studies I’ve been building a real application called Nautix — a modular, container-based automation platform that ties together everything I’ve learned so far.

Link to my GitLab Repo

Blog post #10

Up until now, Nautix has been running using Docker Compose. That worked well in the early stages, but for Blueprint 4.3 – Package and deploy a solution by using Kubernetes, it was time to take the next step.

In this post, I’ll show how I migrated parts of Nautix to Kubernetes, running locally on my development laptop, and how that maps directly to the CCIE Automation blueprint.

Why Kubernetes?

Docker Compose is great for local development, but Kubernetes gives you:

• Declarative deployments

• Built-in health checking and self-healing

• Native secrets and configuration management

• Service discovery and load balancing

• A consistent operational model across environments

Local Kubernetes setup using kind

For local development, I chose kind (Kubernetes IN Docker).

Why kind?

• Lightweight and fast

• Runs entirely inside Docker

• Perfect for labs and experimentation

• Uses real Kubernetes APIs and tooling

Prerequisites

• Docker Desktop (with WSL2 integration)

• kubectl

• kind

Create a kind cluster with ingress support

I created the cluster with explicit port mappings so the ingress controller could be reached from my laptop:

# kind-nautix.yaml
kind: Cluster
apiVersion: kind.x-k8s.io/v1alpha4
nodes:
  - role: control-plane
    extraPortMappings:
      - containerPort: 80
        hostPort: 80
      - containerPort: 443
        hostPort: 443

Create the cluster:

kind create cluster --name nautix --config kind-nautix.yaml

Install ingress-nginx:

kubectl apply -f \
https://raw.githubusercontent.com/kubernetes/ingress-nginx/main/deploy/static/provider/kind/deploy.yaml

At this point, I had a fully functional Kubernetes cluster running locally.

Namespace: isolating Nautix

First, I created a dedicated namespace:

apiVersion: v1
kind: Namespace
metadata:
  name: nautix

kubectl apply -f k8s/00-namespace.yaml
kubectl config set-context --current --namespace=nautix

Namespaces are a simple but powerful concept — they provide isolation and make it much easier to reason about resources.

Handling secrets

In Docker Compose, secrets often end up in .env files.
In Kubernetes, secrets are first-class objects.

Instead of committing secrets to Git, I created them imperatively using kubectl:

kubectl create secret generic nautix-secrets \
  --from-literal=VAULT_DEV_ROOT_TOKEN_ID=root-token \
  -n nautix

This creates a native Kubernetes Secret that can be safely referenced by Deployments without storing sensitive values in source control.

Deploying the Inventory service

The Inventory service is a stateless Flask API, making it a perfect candidate for a Deployment.

Inventory Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: inventory
  namespace: nautix
spec:
  replicas: 1
  selector:
    matchLabels:
      app: inventory
  template:
    metadata:
      labels:
        app: inventory
    spec:
      containers:
        - name: inventory
          image: nautix-inventory:dev
          ports:
            - containerPort: 8000
          readinessProbe:
            httpGet:
              path: /healthz
              port: 8000
            initialDelaySeconds: 3
          livenessProbe:
            httpGet:
              path: /healthz
              port: 8000
            initialDelaySeconds: 10

Inventory Service

apiVersion: v1
kind: Service
metadata:
  name: inventory
  namespace: nautix
spec:
  selector:
    app: inventory
  ports:
    - port: 8000
  type: ClusterIP

Deploying Vault with persistent storage

Vault runs in dev mode for this lab, but I still wanted to demonstrate volumes and persistent storage.

PersistentVolumeClaim

apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: vault-data
  namespace: nautix
spec:
  accessModes:
    - ReadWriteOnce
  resources:
    requests:
      storage: 1Gi

Vault Deployment

apiVersion: apps/v1
kind: Deployment
metadata:
  name: vault
  namespace: nautix
spec:
  replicas: 1
  selector:
    matchLabels:
      app: vault
  template:
    metadata:
      labels:
        app: vault
    spec:
      containers:
        - name: vault
          image: vault:1.8.7
          ports:
            - containerPort: 8200
          env:
            - name: VAULT_DEV_LISTEN_ADDRESS
              value: "0.0.0.0:8200"
            - name: VAULT_DEV_ROOT_TOKEN_ID
              valueFrom:
                secretKeyRef:
                  name: nautix-secrets
                  key: VAULT_DEV_ROOT_TOKEN_ID
          volumeMounts:
            - name: data
              mountPath: /vault/file
      volumes:
        - name: data
          persistentVolumeClaim:
            claimName: vault-data

Vault Service

apiVersion: v1
kind: Service
metadata:
  name: vault
  namespace: nautix
spec:
  selector:
    app: vault
  ports:
    - port: 8200
  type: ClusterIP

Exposing services with Ingress

To expose the services externally, I used host-based routing via Ingress:

apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: nautix
  namespace: nautix
spec:
  ingressClassName: nginx
  rules:
    - host: inventory.nautix.local
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: inventory
                port:
                  number: 8000
    - host: vault.nautix.local
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: vault
                port:
                  number: 8200

With the appropriate host entries on my laptop, I could now access:

• http://inventory.nautix.local

• http://vault.nautix.local

Spinning everything up

With all manifests in place:

kubectl apply -f k8s/

Verify:

kubectl get pods
kubectl get svc
kubectl get ingress

At this point, both Inventory and Vault were running fully inside Kubernetes.

Managing pod lifecycle with kubectl

This is where Kubernetes really shines.

Scaling

kubectl scale deploy inventory --replicas=3
kubectl get pods -l app=inventory

Logs

kubectl logs deploy/inventory
kubectl logs -f deploy/inventory

Self-healing

kubectl delete pod <inventory-pod>

The pod is automatically recreated — no manual intervention required.

Health checks and self-healing

Instead of Docker Compose depends_on, Kubernetes uses readiness and liveness probes.

• Readiness controls whether traffic is sent to a pod

• Liveness controls when a pod should be restarted

This makes the platform far more resilient by default.

Closing thoughts

By migrating even a small part of Nautix to Kubernetes, I was able to demonstrate every requirement in Blueprint 4.3 using real workloads:

• Declarative deployments

• Secure secret handling

• Persistent storage

• Ingress routing

• Health checks

• Scaling and lifecycle management

• Full control via kubectl
